a . Instrument Panel Controls and Indicators.
INSTRUMENT PANEL LEFT SIDE
1 . Hand THROTTLE control. Sets
5. Engine START button (on trucks
engine to any speed without stepping
with LD 465-1 engines). When
o n accelerator pedal. When hand
p r e s s e d in, r o u t e s current to starter
THROTTLE control knob is pulled
t o crank engine. On trucks with
out it locks in any position. Turning
LDS 427-2 engines the start button
knob right or left unlocks it.
is mounted on the cab floor. ( R e f e r
2. ENG. STOP control. When pulled
C o n t r o l s and Indicators.)
out, stops engine by cutting off fuel.
6. Air filter indicator. Shows red when
3. ACCESSORY power switch. When in
engine air filter needs cleaning.
the ON position, routes power to the
s t a r t e r system, instrument panel
7. Windshield wiper control knob. When
gages, fuel pump and low pressure
t u r n e d to on position, starts wind-
w a r n i n g buzzer.
s h i e l d wipers.
4. Light switch. T u r n s truck lights
8. MANIFOLD HEATER SWITCH. When
on or off.
set to ON position, starts manifold
h e a t e r . Manifold heater is used to
help start and warmup the engine
when outside temperature is below
+20F .
