TM 9-2320-211-10-1
Installing Front and Side Racks on Dropside Type Cargo Trucks.
e.
I
FRAME 1
Put side racks with seats ( 1) into sockets (2) on right and left sides of truck.
1.
2.
Put front rack (3) into front rack sockets (4) .
Put bow storage side racks (5) into their sockets.
3.
Line up retaining rings (6) and lock with locking pins (7) .
4.
GO TO FRAME 2
TA 053902
