TM 9-2320-279-10-2
M984E1 General Operating Procedures (Cont)
2-78. TOW M520 (CONT).
(8) Remove two M977 front adapters (11) from crosstube (7) and place on
equipment body floor (12).
(9) Remove M520 towing adapters from equipment body floor (12).
CAUTION
Do not contact pintle hook with lift cylinder. Equipment
damage may result.
(10) Extend both tow cylinders (2) approximately 12 in. (30 cm). Extend lift
cylinder (13) until bottom of retrieval assembly is approximately 2 in.
(51 mm) above ground.
2-320
