Left Landinq Leq Installation
Figure 4-57. Float Pad

TM-9-2330-358-14-P Semtrailer Tactical Dual Purpose Breakbulk/Container Transporter 22-1/2 Ton M871 M871A1 Manual Page Navigation
  152    153    154    155    156  157  158    159    160    161    162
TM9-2330-358-14&P
j. Crank Installation.
NOTE
The seal (6) is on the M871 semitrailer only.
(1) Install seal (6, fig. 4-53) and crank (5).
(2) Install washer (4), bolt (3), washer (2) and nut (l).
(3) Install float pad in bracket.
(4) Check operation of landing legs.
(5) Make sure landing legs are fully lowered and remove jack stands.
TASK ENDS HERE
4-56.
FLOAT PADS (GROUND BOARD ASSEMBLY)
This task covers:
Removal
Installation
INITIAL SETUP
Tools
Personnel Required
TWO
Grinder, portable
Torch, acetylene
Welder, arc
General mechanics tool kit
a.
Handle Removal.
(1) Remove two nuts (1, fig. 4-57), washers (2) and bolts (3) from float pad
handle (4).
(2) Remove handle (4)
q
--.
b
Chain Removal.
--
WARNING
Wear welding mask, gloves, and apron when welding or
using cutting torch.  Failure to wear adequate
protective clothing may result in serious injury.
