TM 9-2330-394-13&P
EQUIPMENT DESCRIPTION AND DATA - Continued
0002 00
EQUIPMENT DATA - Continued
WARNING
Do not exceed maximum speed and grade limitations during normal
operations. Do not exceed maximum side slope or departure angles or ford
water greater than maximum depth. Failure to comply may result in serious
injury or death to personnel.
Table 7. Trailer Performance Data provides information for the LMTVT (M1082) and MTVT (M1095).
Table 7. Trailer Performance Data.
Minimum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Ground
Grade
Side
Departure
Fording
Speed
Speed
Clearance
Ability
Slope
Angle
Depth
(primary
(primary
Ability
(without
roads, 3%
roads, 2%
preparation)
grade)
grade)
35 mph (56
25 mph (40
60 in.
LMTVT: 16.5
30%
30%
LMTVT: 25
km/h) if
km/h) if
(152.4 cm)
in. (41.9 cm)
degrees
towed by
towed by
FMTV tractor
FMTV
MTVT: 14.5
MTVT: 40
or wrecker.
tractor or
in. (36.8 cm)
degrees
wrecker.
45 mph (72
km/h) all
40 mph (64
other FMTVs.
km/h) all
other
FMTVs.
Table 8. System Data provides detailed information for the major components of the FMTV trailers.
Table 8. System Data.
VOLTAGE REGULATOR
Make
.................................................................................................................. Dantronics, Inc.
Model ..............................................................................................................................DT325B
Type
............................................................................... Solid State, 12/24 VDC negative ground
AXLES
Make
...............................................................................................................................Meritor
Type
........................................................................................................................ Non-driving
SUSPENSION SYSTEM
Make
.................................................................................................................... Standen's Ltd.
Type
............................................................................................................ Multiple Leaf Spring
0002 00-8
