TM 9-2330-394-13&P
PREVENTIVE MAINTENANCE CHECKS AND SERVICES,
0042 00
INCLUDING LUBRICATION INSTRUCTIONS - Continued
Semiannual PMCS Procedures for Trailer (Field Level) - Continued
Table 10. Preventive Maintenance Checks and Services (PMCS) - Semiannual (Field Level) -
Continued.
FIELD-LEVEL MAINTENANCE
EQUIPMENT
ITEM
INTERVAL
MAN-  ITEM TO BE
HOUR CHECKED OR PROCEDURE
NOT READY/
NO.
AVAILABLE IF:
SERVICED
12
Semiannual
0.3
Lifting Beams  Check if six months have passed
since lifting beam (28) has been
lubricated. If lifting beam has not
been lubricated, perform the
following:
1. Remove left and right lifting beams
(WP 0105 00, Lifting Arm Bracket
Replacement).
WARNING
Dry Cleaning Solvent (P-D-680) is TOXIC and flammable. Wear protective goggles and
gloves; use only in well-ventilated area; avoid contact with skin, eyes, and clothes, and do not
breath vapors. Keep away from heat or flame. Never smoke when using Dry Cleaning
Solvent; the flashpoint for Type I Dry Cleaning Solvent is 100 F (38 C) and for Type II is 138
F (50 C). Failure to comply may result in serious injury or death to personnel.
If personnel become dizzy while using Dry Cleaning Solvent, immediately get fresh air and
medical help. If Dry Cleaning Solvent contacts skin or clothes, flush with cold water. If Dry
Cleaning Solvent contacts eyes, immediately flush eyes with water and get medical attention.
Failure to comply may result in serious injury or death to personnel.
0042 00-74
