TM 9-2330-394-13&P
BRAKE AIR HOSES (MTVT) REPLACEMENT
THIS WORK PACKAGE COVERS:
Brake Air Hose Locations, Operational Check
INITIAL SETUP:
Maintenance Level
Materials/Parts
Field
Cap and Plug Set (Item 6, WP 0176 00)
Dispenser, Pressure Sensitive Adhesive Tape
Tools and Special Tools
(Item 10 WP 0176 00)
Tool Kit, Genl Mech (Item 37, WP 0178 00)
Ties, Cable, Plastic (Item 37, WP 0176 00)
Goggles, Industrial (Item 8, WP 0178 00)
Equipment Conditions
Trailer uncoupled
BRAKE AIR HOSE LOCATIONS
WARNING
Vent air system before disconnecting airlines. Pressurized air can blow dirt
and debris with sufficient force to cause injury. Safety goggles must be worn
when working with compressed air. Failure to comply may result in injury to
personnel.
Wear appropriate eye protection when working under trailer due to the
possibility of falling debris. Failure to comply may result in injury to
personnel.
CAUTION
Cap or plug hose connections to prevent contamination. Failure to comply may result in
damage to equipment.
NOTE
This task shows locations of hoses on the trailer. It may not be necessary to remove all
hoses at one time.
Tag hoses and connection points prior to removal.
Note location of plastic cable ties prior to removal.
Remove plastic cable ties as required.
0060 00-1
