TM 9-2330-394-13&P
REAR BUMPER REPLACEMENT
THIS WORK PACKAGE COVERS:
Removal, Installation, Operational Check
INITIAL SETUP:
Maintenance Level
Materials/Parts
Field
Bolt (4) (Item 25, WP 0181 00)
Nut, Self-Locking (4) (Item 35,
Tools and Special Tools
Tool Kit, Genl Mech (Item 37, WP 0178 00)
Personnel Required
Wrench, Torque, 0-600 lb-ft
Two
(Item 52, WP 0178 00)
Wrench Set, Socket (Item 46, WP 0178 00)
Equipment Conditions
Goggles, Industrial (Item 8, WP 0178 00)
Rear crossmember removed (WP 0108 00).
Wrench, Impact, Electric (Item 42,
Socket Set, Impact (Item 28, WP 0178 00)
Sling, Cargo (Item 27, WP 0178 00)
WARNING
Wear appropriate eye protection when working under trailer due to the
possibility of falling debris. Failure to comply may result in injury to
personnel.
NOTE
Left and right sides of rear bumper are removed the same way. Right side shown.
