TM 9-2350-277-10
ADJUST (T150) TRACK TENSION Continued
0091 01
9.
To loosen track tension, slowly open bleed valve on track tension adjuster to let grease out. Wipe up
excess grease. If track adjuster is in as far as it will go, and track is still too tight, add one track shoe. See
task: REMOVE/INSTALL (T150) TRACK SHOE (WP 0093 01) and readjust track tension Steps 5 9.
BLEED
TRACK
VALVE
ADJUSTER
END OF TASK
0091 01-3/4 blank
Change 2
