ARMY TM 9-4120-380-14
NAVY EE-000-BA-MMA-010/7053-AC
AIR FORCE TO 35E9-136-21
4.32 RESISTORS (R1-R7) This task covers inspection, testing, removal and installation
INITIAL SETUP
Tools
Tool kit, service, refrigeration unit (Item 1, Appendix B)
Personnel 1
Materials
Equipment Conditions:
Disconnect input power to the air conditioner before performing any internal
maintenance. Voltages used can KILL. Shutting the unit off at the control panel does not
disconnect unit power
(1) Disconnect air conditioner input power at source,
INSPECTION
Check resistors for signs of overheating or other visible damage Replace if damaged (see fig 4-23).
TESTING
Using multimeter, measure each resistor for proper resistance Resistance should measure 2850-3150 ohms. Replace if
damaged.
REMOVAL
Unsolder damaged resistors (2) and remove from resistor board (1).
INSTALLATION
Solder resistors (2) to resistor board (1).
4-65
