Figure 5-18. Charging Valves (V1 and V6)
CONDENSER COIL (C) - TM-9-4120-403-140266
TM-9-4120-403-14 Air Conditioner Vertical Compact 6 000 BTU/HR 115 Volt. Single Phase 50/60 Hertz Model JHAA/C6V1 NSN 4120-01-327-5447 Manual
Page Navigation
253
254
255
256
257
258
259
260
261
262
263
TM
9-4120-403-14
(1)
Replace
the
dehydrator.
(See
para
5-23.)
(2)
Purge
system.
(See
para
5-8.)
(3)
Leak
test
all
newly
connected
joints
and
those
in
the
repaired
area.
(See
para
5-10.)
(4)
Evacuate
the
refrigeration
system.
(See
para
5-11.)
(5)
Charge
the
refrigeration
system.
(See
para
5-12.)
(6)
Install
top
panel.
(See
para
4-16.)
(7)
Install
charging
valve
access
cover.
(See
para
4-13.)
5-63
