TM 9-4120-403-14
Replacement
(1)
Use a drill bit slightly smaller than the rivet body to drill old rivets out.
(2)
Remove handle.
(3)
Rivet replacement handle in place.
(4)
Seal perimeter of handle with sealant.
6-4. BLIND NUTS AND RIVET PLATES
This task covers:
a. Replacement
INITIAL SETUP
Tools
Tool Kit, Refrigeration
Drill (part of shop maintenance kit)
Drill Bit Set (part of shop maintenance kit)
Riveter
Materials/Parts
Blind Nuts
(As Required)
Rivets
(As Required)
Replacement
a.
Blind nuts (rivnuts)
(1)
Carefully drill the old blind nut out using a drill slightly smaller than the body of the blind nut.
(2)
Install replacement part.
6-3
