TB 55-1935-204-12
SECTION V. ACCESSORY ITEMS ALL HULLS (NON-BILL) - Continued
National
Stock
Description
U/I
Qty
Rec
Number
Shackle, 2-1/2" stock, 4" Between Eyes 10-1/2"
EA
6
Inside Length, (81348), RR-271, Type
IV, Class 1
Sling Assembly, LARC-LX, Modified To Include
EA
2
NEWCO W-10 Slip Through Thimbles At
Each End And Two Legs Connected At Top
With Alloy Master Link Rated At 60 Tons
Vertical, (97313), LX-05-012- 0008
Sling, Nylon, 24 Ft. Type 7, 2 Ply, 2" Wide with
EA
2
Cordura-Lined Eyes and Body, Rated at 6,400
lbs. Vertical, (8D826), FE-2-902
Sling, Nylon, 40 Ft. Type 7, 6" Wide, 4 Ply With
EA
2
Cordura-Lined Eyes and Body; Rated at
23,680 Ibs. Vertical, (8D826), FE-4-904
SLWT Lift Assembly As Identified in NAVSEA.
EA
1
(53711), DAG No.,6155101,
Lift Assembly, LCM-8 As Identified in NAVSEA.
EA
1
(53711), DAG No.,5103217,
Leg Wire Rope Sling, 4, With Thimble Eyes All
EA
1
Ends, 5 Ton Latched Eye Hoist Hooks At
Bottom , And 1-1/2" Alloy Master Link At Bot-
tom And 2" Diameter Oblong Alloy Master
Link At Top; Rated 13 Tons At 30 Degrees,
5/8" X 12 Ft., (8D826), JHH- LDL-458-12,
Leg Wire Rope Sling, 4, With Thimble Eyes All
EA
1
Ends, 10 Ton Latched Eye Hoist On Bottom,
And 2" Diameter Oblong Alloy Master Link
At Top; Rated 33 At 30 Degrees, 1" X 30 Ft.,
(8D826) ,JHH- LDL-41-30,
Wire Rope Sling With 10 Ton Latch Eye Hoist
EA
4
Hook One End; Rate At 6.9 Tons Vertical, 1" X
20 Ft.. Type 5 (Thimbles Each End), (8D826),
JHH- LDL-11-20
Change 1 29
