TM 9-2320-211-10-1
FRAME 2
I
Turn BATTERY switch (1) to ON position.
1.
CAUTION
Do not hold START button (2) in for more than ten
seconds at one time. If engine does not start in ten
seconds, wait two minutes before pressing START
button again. Do not press START button while head-
lights are on. Doing either of the above may cause
damage to the starter or battery.
2.
Press engine START button (2) to crank engine and step down on accelerator
pedal (3) a little until engine starts.
Let clutch pedal (4) up slowly as soon as engine starts.
3.
G O TO FRAME 3
4-38
