TM 9-2320-360-10
7
Right Turn Indicator
Flashes (green) when right turn signal is on.
8
Beacon Light Switch
Two-position switch used to control rotating beacon light. Push beacon light switch up to turn light
off and down to turn light on.
9
Work Light Switch
Two-position switch used to control work light.
10
Dome Light Switch
Two-position switch used to control dome light.
11
Headlights Switch
Three-position switch used to control headlights, clearance lights, and parking lights. BLACK OUT
LIGHTS switch must be in off position before these lights will operate.
12
Instrument Panel Lighting Control
Used to control brightness of instrument panel lights.
13
Windshield Wiper Switch
Three-position switch used to operate and control speed of windshield wipers.
14
Windshield Washe r Switch
Momentary switch used to control windshield washer.
15
Deleted
16
BLACK OUT MARKER Switch
Two-position switch used to control blackout marker lights. BLACK OUT LIGHTS switch must be in
on position before blackout marker lights will operate.
17
BLACK OUT DRIVE Switch
Two-position switch used to control blackout driving lights. BLACK OUT LIGHTS switch must be in
on position before blackout driving lights will operate.
18
BLACK OUT LIGHTS Switch
Two-position switch used to control BLACK OUT DRIVE and BLACK OUT MARKER switches.
When turned on, other lighting is inoperative.
2-5
