TM 9-2320-366-10-2
2-42. 30K WINCH OPERATION (CONT)
(39) Raise stifflegs (para 2-40c).
(40) Set engine speed to idle (750 rpm) by decreasing HAND THROTTLE lever (5) to full
down position.
(41) Position PTO switch (4) to off.
(42) Shut down engine (para 2-27f).
(43) Disconnect wrecker remote control (para 2-44c).
(44) Notify Unit Maintenance to clean and lubricate cable.
b. 30K Winch Operation without Load.
(1) Press N (Neutral) button (1) on WTEC II TEPSS (2) or WTEC III TPSS (2).
2-456
