TM 9-2320-366-10-2
2-49. M1078 AND M1083 SERIES TOWING CONNECTION/
DISCONNECTION (CONT)
NOTE
Perform steps (12) and (13) if tow interconnect cable was used to power
M1078/M1083 composite taillights.
(12) Disconnect tow interconnect cable (11) from M1089 rear electrical connector (9).
(13) Disconnect tow interconnect cable (11) from M1078/M1083 front electrical connector
(12).
2-636
