TM 9-2330-203-14&P
4-30. AIR LINES, FITTINGS, AND HOSES REPLACEMENT (M198A1) (Con't).
b. INSTALLATION
NOTE
Apply antiselzing tape to all male threads.
1.
Slide clamp (4) on tube assembly (3). Install clamp on frame with screw (7), new lockwasher (6), and nut (5).
2.
Install adapter (11) in emergency relay valve (10).
3.
Install elbow (2) in airbrake chamber (1).
4.
Connect tube assembly (3) to elbow (2) on airbrake chamber (1) and adapter (11) on emergency relay valve
(10).
5.
Install adapter (9) in emergency relay valve (10).
6.
Install elbow (16) in pressure tank (14).
7.
Connect tube assembly (8) to elbow (16) on pressure tank (14) and adapter (9) on emergency relay valve (10).
8.
Install elbow (12) in emergency relay valve (10).
9.
Install elbow (17) in air filter (18).
NOTE
Clamp Is mounted on left side only.
10.
Feed tube assembly (13) through clamp (15) and connect to elbow (17) on air filter (18) and elbow (12) on
emergency relay valve (10). Ensure that pressure tank (14) mounting is installed and clamp is secure around
tube assembly.
11.
Install tee (19) in air filter (18).
12.
Install two grommets (20) in frame.
13.
Install two Identification plates (25) and terminal bolts (27) in frame using two new lockwashers (24) and nuts
(23).
14.
Install two adapters (22) in terminal bolts (27).
15.
Connect two tube assemblies (21) to tee (19) and adapters (22).
16.
Connect each intervehicular air hose (26) to terminal bolt (27).
17.
Repeat steps 8 through 16 for other side of dolly.
18.
Close stowage compartment cover.
4-74
