TM 9-2330-247-14&P
4-38. AIRBRAKE CHAMBER (Con't)
ACTION
REMARKS
ITEM
LOCATION
Put in place.
Rod (25) and
Spring (22)
24.
retainer (24)
Body (19)
Put in place.
25.
Diaphragm (26)
Fifteen bolts (17),
a. Line up matchmarks.
26.
Cover (27) and
b. Squeeze cover (27) and body (19) together.
Iockwashers (20),
body (19)
and nuts (21 )
c. With aid of an assistant, screw in mounting
hardware and tighten using in. socket, ratchet
handle with
in. drive, and
in. box-end
wrench.
Leave marked hole open for long screw
(1).
INSTALLATION
Put in place.
Bracket (12)
27.
Frame (7)
Three screws
Screw in and tighten using
in. socket, ratchet
Bracket (12)
28.
in. drive, and
in. open-end box
handle with
(5) and self-
and frame (7)
Iocking nuts (4)
wrench.
Airbrake chamber
Put in place.
Bracket (12)
29.
(14)
and master
cylinder (9)
Put in place.
Frame (7) and
Support (2)
30.
airbrake
chamber (14)
Screw in long screw (1) and tighten using
in.
Long screw (1)
support (2)
31.
in. drive, and
in.
socket, ratchet handle with
and self-locking
and airbrake
box-end wrench.
nut (3)
chamber (14)
TA701092
4-82
