SECTION
II
TM9-2330-287-14&P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
FSCM
NUMBER
DESCRIPTION AND USABLE ON CODE (UOC)
QTY
GROUP 18 BODY
1801 BODY ASSEMBLY
FIG. 23. BODY COMPONENTS
1
PAOZZ
19207
11636658
COVER,ACCESS
1
2
PFOZZ
19207
12312978
BRACKET,DOUBLE ANGL
1
UOC:A60
3
PAOZZ
96906
MS35338-44
WASHER,LOCK
16
4
PAOZZ
96906
MS35308-305
SCREW,CAP,HEXAGON H
4
UOC:A08
4
PAOZZ
96906
MS35308-306
SCREW,CAP,HEXAGON H TOP REACH TUBE
4
PLATES RETAINING
UOC:A60
5
PAOZZ
19207
11636717
GASKET
1
6
PAOZZ
19207
11636653
COVER,ACCESS
1
7
PFOZZ
19207
12296618
STRAP,RETAINING
1
8
PAOZZ
96906
MS35308-307
SCREW,CAP,HEXAGON H
8
UOC:A08
8
PAOZZ
96906
MS35308-307
SCREW,CAP,HEXAGON H
10
UOC:A60
9
PAOZZ
96906
MS35308-305
SCREW,CAP,HEXAGON H
2
UOC:A08
9
PAOZZ
96906
MS35308-305
SCREW,CAP,HEXAGON H
2
UOC:A60
10
PAOZZ
19207
11636574
SPACER,PLATE
1
11
PAOZZ
96906
MS35338-46
WASHER,LOCK
2
12
PAOZZ
96906
MS35308-305
SCREW,CAP,HEXAGON H
2
UOC:A08
13
PAOZZ
96906
MS35308-364
SCREW,CAP,HEXAGON H
2
UOC:A60
14
PAOZZ
19207
11636652
YOKE,RETRACTABLE SU
1
15
PAOZZ
96906
MS16633-1050
RING,RETAINING
1
16
PAOZZ
19207
11636651
HANDLE,RETRACTABLE
1
17
PAOZZ
96906
MS16633-1025
RING,RETRAINING
1
18
PFOZZ
19207
11636650
PIN,GROOVED,HEADED
1
19
PAOZZ
19207
8331541
SPRING,HELICAL,COMP
1
20
PAOZZ
19207
7979971
PIN,STRAIGHT,HEADLE
1
21
PAOZZ
19207
8331542
WASHER,RECESSED
1
22
PAOZZ
19207
11636681
PLATE, REACH TUBE, LEFT FRONT
1
23
PAOZZ
19207
11636656
GASKET
2
24
PAOZZ
19207
11636657
PLATE,WELDMENT
1
END OF FIGURE
23-1
