SECTION
II
TM9-2330-358-14&P
C01
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC)
QTY
GROUP 1202 SERVICE BRAKES
*1
PAOFF
62707
M16WN101X
BRAKE SHOE AND LINING ASSEMBLY
4
UOC:V79
*1
PAFFF
62707
M16WN121-1X
BRAKE SHOE
4
UOC:WAA
2
PAFZZ
62707
M16WL112-2
.LINING,FRICTION
2
UOC:WAA
3
PAFZZ
62707
M16WL112-1
.LINING,FRICTION
2
UOC:WAA
4
PAFZZ
89346
93931R96
.BRAKE LINING KIT
1
UOC:V79
5
PAFZZ
62707
M10HM100
.RIVET,TUBULAR
48
UOC:WAA
5
PAFZZ
62707
M10HM160
.RIVET
16
UOC:V79
6
PAFZZ
62707
M16WS104X
.BRAKE SHOE
4
UOC:WAA
6
PAOZZ
62707
M16SW132-X
.BRAKE SHOE
2
UOC:V79
7
PAOZZ
62707
31624
RING,RETAINING
8
*8
XDOZZ
62707
M10HP104
PIN,GROOVED,HEADLES ANCHOR
4
UOC:V79
8
PAOZZ
62707
M10HP102
PIN,GROOVED,HEADLES
4
UOC:WAA
9
PAOZZ
62707
M10HN135
WASHER,FLAT ANCHOR PIN
8
UOC:V79
9
PAOZZ
62707
M10HN103
WASHER,FLAT
8
UOC:WAA
10
PFFZZ
62707
M16HD101
BUSHING,SLEEVE
4
UOC:WAA
* 11
PAOZZ
56697
207100
PIN,BRAKE SPRING RETRACT SPRING
4
UOC:V79
11
PAOZZ
62707
M16WJ102
CLIP,RETAINING
4
UOC:WAA
12
PAOZZ
62707
M16WJ104
PIN,SHOULDER,HEADLE
4
13
PAOZZ
62707
M16WJ103
SPRING,HELICAL,TORS
4
14
PAOZZ
62707
M16WJ100
SPRING,HELICAL,EXTE SLACK ADJUSTER
2
RETRACTER
END OF FIGURE
14-1
