SECTION II
TM9-2330-368-14&PC01
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 1504 SPARE WHEEL CARRIER AND
TIRE LOCK
FIG. 11 SPARE TIRE CARRIER
*
1
XDOOO
22271
D7914
CARRIER,TIRE
1
*
2
XAOZZ
22271
D9914
.MAINMEMBER (WELDER TO FRAME)
1
*
3
PAOZZ
96906
MS51922-1
.NUT,SELF-LOCKING,HE
3
*
4
PAOZZ
22271
B9912
.PAWL PLATE ASSEMBLY
1
*
5
PAOZZ
96906
MS90725-8
.SCREW,CAP,HEXAGON H
3
*
6
XDOZZ
22271
A7918
.ROPE,WIRE
1
*
7
PAOZZ
22271
B9913
.SHAFT ASSEMBLY
1
*
8
PAOZZ
09386
37888
.NUT,PLAIN,SINGLE BA
4
*
9
PAOZZ
71747
CHF-H92-1/4
.CLAMP,WIRE ROPE,SAD
2
*
10
PAOZZ
96906
MS35338-45
.WASHER,LOCK
4
*
11
PAOZZ
96906
MS24665-495
.PIN,COTTER
1
*
12
PAOZZ
96906
MS27183-27
.WASHER,FLAT
2
END OF FIGURE
11-1
