TM 9-2330-384-14&P
Section II.
MAINTENANCE ALLOCATION CHART (Con't)
(4)
(5)
(6)
Maintenance Level
Unit
DS
GS
Depot
Maintenance
Function
C
O
F
H
Remarks
(Con't)
CAMSHAFT
REPLACE
1.5
SHOE AND LINING
REPLACE
1.5
REPAIR
0.6
1206
SLACK ADJUSTER
ADJUST
0.2
REPLACE
1.0
1208
AIR BRAKE SYSTEM
COUPLING, AIR
REPLACE
1.0
CHAMBER, AIR
REPLACE
2.0
VALVE ASSEMBLY
INSPECT
0.2
REPLACE
2.0
LINES, FITTINGS, BRAKE
INSPECT
0.2
INTERLOCK, AND HOSES
REPLACE
1.0
REPAIR
1.5
AIR RESERVOIRS
REPLACE
1.5
13
WHEELS
1311
WHEEL ASSEMBLY
BEARING. HUB
INSPECT
0.3
SERVICE
1.0
REPLACE
1.5
ADJUST
0.3
WHEEL
REPLACE
1.5
DRUM, BRAKE
INSPECT
0.3
REPLACE
1.0
REPAIR
2.0
SEALS AND WIPERS
INSPECT
0.3
REPLACE
1.5
1313
TIRES
INSPECT
0.1
SERVICE
0.4
REPLACE
1.0
REPAIR
1.0
NUTS, STUDS, AND
INSPECT
0.3
WHEEL RINGS
ADJUST
0.5
REPLACE
1.0
B-4
