SECTION II
TM9-2330-386-14&P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC)
QTY
GROUP 1208
AIR BRAKE SYSTEM
FIG. 14
SPRING BRAKE CHAMBER
1
PAOZZ
56878
31FAF-1011
NUT,SELF-LOCKING,HE
4
2
PAOZZ
78500
1229U1503Z
WASHER,FLAT
4
3
PAOZZ
4B100
3130300
CHAMBER,AIR BRAKE
2
4
KFOZZ
4B100
8019011
CAP,DUST,PLASTIC PART OF KIT P/N
1
9019002
5
KFOZZ
4B100
8120007
SCREW,ROUND HEAD PART OF KIT P/N
1
9019002
END OF FIGURE
14-1
