TM 9-2330-394-13&P
LANDING GEAR AND WINCH REPLACEMENT/REPAIR - Continued
0104 00
WINCH REMOVAL
WARNING
Wear appropriate eye protection when working under trailer due to the
possibility of falling debris. Failure to comply may result in injury to
personnel.
1.
Remove landing gear winch cable (WP 0086 00, Removal).
2.
Remove cotter pin (33) from clevis pin (34). Discard cotter pin.
3.
Remove clevis pin (34) from winch handle (35).
4.
Remove winch handle (35) and bushing (36) from winch (37).
0104 00-23
