TM 9-2350-222-10-2
PREPARE FOR FIRING (REMOVE COVERS) - Continued
To Remove and Stow 7.62-MM Machine Gun Cover:
Tools:
Get flat-tipped screwdriver (A) from right front fender box (B).
Make Sure:
Turret traversing lock is
ELEV/TRAV POWER switch
(C) is set to OFF.
1. Using screwdriver (A), loosen screw (D).
2. Pull cover (E) from housing (F).
3. Remove clamp (G) from cover (E).
4. Replace clamp (G) on housing (F).
5. Using screwdriver (A),
tighten screw (D).
6. Place cover (E) in right front fender box (B).
7. Return screwdriver (A) to stowage.
2-330
TA132470
