C-8-104
CODE NO.
CM-8-53
Z-6-54
JOB SELECTOR
UNITS PER
PART NO.
INDEX
ASS'Y
DESCRIPTION
NO.
Job Selector (1612-U, 3012-U, 1611-H, 2612-1H, 2013,
46817
Ref.
2013-0, 2012-A, 2012-AT, 1612-0, 3613-0, 1612, 3612,
2013-1,2013-10, 2012-1A, 2012-1AT)
*43560
Job Selector (1612-1, 3613-1, 2612-1, 2613-2, 6013-2,
*Ref.
2618-4, HS-6013, ZW-3620, ZV-3620, ZS-3620)
1
1
Jab Selector Dial
22078
2
4
Outer Edge Felt
6-14304
3
1
Job Selector Plate
400838
4
1
Screw, Hex. Hd. Cop 5/16-18NC x 3/4
198027
1
Acorn Nut 5/16-18NC
4449
5
USE
Bushing
6
6-14401
ONE
Bushing
*2701
4
Screw, Rd. Hd. Mach. 1/4-20NC x 1/4
*7
198890
4
199374
Washer, Lock Shakeproof 1/4 Internal
*8
4
Nut, Hex. Jam 1/4-20NC
*9
199114
1
Job Selector Frame
42672
*10
NOTE: Job Selectors #46817 & #43560 First Used 9/17/62. Before This Date 400838 Plate and 22078
Dial, Must Be Replaced Together as a Unit.
*NOTE: Starred Items Used Only On Assembly #43560.
*NOTE: Last Used On Models:
LAST MACH.
MODEL
150-69593
1613-2
151-69515
3613-2
152-691017
1612-3
198-69361
2613-3
153-691054
3612-3
199-70125
6013-3
288-69204
1612-H
284-69135
2612-H
206-69308
2612-2H
272-69152
3612-H
C-6
