H1-13.0
CODE NO.
DBW-15 BUTT WELDER ASSEMBLY
UNITS PER
PART NO.
INDEX
ASS'Y.
DESCRIPTION
NO.
401436
DBW-15 Portable Assembly
Ref.
4
199019
. Screw, Truss Hd. Mach. 1/4-20NC x 3/8
1
4
199356
. Washer, Lock 1/4 Shakeproof Int
2
1
131807
. Blade Shear Assembly (See Detail)
3
1
59788
Butt Welder Assembly (See Detail)
4
1
. Data Plate
116552
5
4
. Screw, Rd. Hd. Drive #2 x 3/16 Type "U"
199396
6
USE
Butt Welder Box Assembly (Std. 240 Vac.)
132814
7
ONE
Butt Welder Box Assembly (Above 240 Vac.)
132815
USE
.Butt Welder Box
6-06342
8
ONE
.Butt WELDER Box
50528
4
. . Spacer (Sq. D Switch Only) (#132815 Only)
1927
9
USE
. . Safety Switch 39010
132821
10
ONE
. . Safety Switch 39010
16180
1
. . Transformer (#132815 Only)
408838
11
4
. . Screw, Rd. Hd. Mach. 1/4-20NC x 1/2 (#132815 Only)
198895
12
4
. . Washer, Lock 1/4 Std. (#132815 Only)
199321
13
4
. . Nut, Hex 1/4-20NC (#132815 Only)
199115
14
1
15
. . Grommet
7506
4
16
. . Screw, Rd. Hd. Mach. 1/4-20NC x 3/4
198897
4
17
. . Washer, Lock 1/4 Std.
199321
2
. . Fuse 10A-250 V
133848
18
2
. . Fuse 5A-600 V
133861
1
. . Ground Tag
104770
19
1
. . Escutcheon ("Warning ---")
133160
20
4
. . Screw, Rd. Hd. Drive #2 x 3/16 Type "U"
199396
21
Following Items Not Shown:
A.R.
. . Wire, #10 AWG Green
STK#714
A.R.
. . Wire, #12 AWG Black
STK#724
H-25
