TM 9-3405-215-14&P
CODE NO.
SLIDING TABLE ASSEMBLY
(AIR FEED)
INDEX
CATALO G
UNITS PER
NO.
NO.
DESCRIPTION
ASS'Y
Ref.
501532
Sliding Table Assembly (1612-0, 1612, 3612, 2614-1, 3612-1, 3613-10)
Ref.
503826
Sliding Table Assembly (2012-A, 2012-1A, 2012-AT, 2012-1AT, 2012-2A)
1
090-042094
. Roll Pin ...................................................................................................
1
2
090-104902
. Center Plate ............................................................................................
1
3
095-013801
. Table.......................................................................................................
1
4
091-253617
. Square Weldment ...................................................................................
1
5
091-988519
. Screw, Rd. Hd. Mach. #8-32 NC x 1/4 ...................................................
2
6
091-295907
. Chain ......................................................................................................
1
7
091-253930
. Plug ........................................................................................................
1
8
091-990192
. Screw, Truss Hd. Mach. 1/4-20 NC x 3/8 .................................................
6
10
095-030458
. Pan ........................................................................................................
1
11
091-988675
. Screw, Rd. Hd. Mach. #10-24 NC x 3/8 ..................................................
16
12
135-065803
. Pipe Plug ................................................................................................
1
13
090-507914
. Trunnion .................................................................................................
1
14
090-036476
. Ball Bushing ...........................................................................................
4
15
090-051806
. Spacer ....................................................................................................
2
16
090-394644
. Head ......................................................................................................
1
17
090-410937
. Chip Guard Assembly (#501532) .............................................................
1
18
090-450800
. Chip Cover Assembly (#501532) ..............................................................
1
19
090-216219
. Trunnion Plate ........................................................................................
1
20
090-409038
. Cradle .....................................................................................................
1
21
090-105016
. Spacer ...................................................................................................
1
22
091-981068
. Screw, Hex. Hd. Cap 3/4-16 NF x 5.........................................................
1
23
091-991414
. Nut, Hex. 3/4-16 NF ................................................................................
1
24
091-980474
. Screw, Hex. Hd. Cap 3/8-16 NC x 1-1/4...................................................
4
25
091-993329
. Washer, Lock 3/8 Std...............................................................................
10
26
135-003283
. Dowel Pin ................................................................................................
2
27
090-242413
. Keeper Block ..........................................................................................
1
28
091-988386
. Screw, Rd. Hd. Mach. 06-32 NC x 1/4" ..................................................
1
29
134-033158
. Pointer ...................................................................................................
1
30
091-988931
. Screw, Rd. Hd. Mach. 1/4-20 NC x 3/8 (#501532) ..................................
2
091-988220
. Screw, Pan Hd. Mach. 1/4-20 NC x 3/8 (#503826) ..................................
2
31
091-993568
. Washer, Lock 1/4 Shakeproof Int .............................................................
8
Lube Fitting 90 .......................................................................................
33
090-087909
.
2
34
106-335185
.
Pipe Plug ................................................................................................
1
35
090-042441
.
Roll Pin ...................................................................................................
1
36
091-046326
.
Belleville Washer ....................................................................................
6
37
091-982520
.
Screw, Soc. Hd. Cap 1/4-28 NF x 1-1/4 ..................................................
1
38
091-156604
.
Locknut ..................................................................................................
1
39
091-310110
.
Handle Sub-Assembly .............................................................................
1
40
091-992644
.
Washer, Flat 3/8 Std. S.A.E.....................................................................
2
Following Items Not Shown:
091-319483
. Guard Assembly (#503826) .....................................................................
1
111-055091
. Pipe Plug (#503826) ...............................................................................
1
090-285271
. Handle Assembly ....................................................................................
1
091-294470
. Screw Assembly .....................................................................................
1
81
