5-14. EVAPORATOR COIL (E)

This task covers:

a. Replacement

INITIAL SETUP

Tools

General Safety Instructions

Tool Kit, Refrigeration

(Appendix B item 1)

WARNING

Drill (part of shop maintenance kit)

(Appendix B item 8)

Toluene is flammable, and its vapors can be explosive.

Drill Bit Set (part of shop maintenance kit)

Repeated or prolonged skin contact or inhalation of

(Appendix B item 8)

vapors can be toxic. Use in a well-ventilated area, and

Riveter

keep away from sparks or flame. Use goggles, gloves

(Appendix B item 9)

and apron when appropriate.

Nitrogen Regulator

(Appendix B item 10)

While handling coils, wear gloves to avoid cuts and

reduce fin damage on coil.

Materials/Parts

Apron

(Appendix E item 5)

Respirator

(Appendix E item 6)

Goggles

(Appendix E item 7)

Gloves, Protective

(Appendix E item 8)

Toluene

(Appendix E item 9)

Adhesive

(Appendix E item 10)

Rivet

(Appendix E item 35)

Nitrogen

(Appendix E item 37)

Brazing Alloy

(Appendix E item 38)

Brazing Flux

(Appendix E item 39)

Refrigerant-22

(Appendix E item 40)

5- 35
