TM 9-4910-720-14&P
RMI-R3
PARTS LIST:
PART NO. RMI-R3-1
FRAME
RMI-R3-2
HYDRAULIC
CYLINDER
RMI-R3-3
WHEEL
RMI-R3-4
WHEEL
AXLE
RMI-R3-5
CASTER
RMI-R3-6
LIFTING
ARM
ASSEMBLY
RMI-R3-7
ROLLER
RMI-R3-8
ROLLER PINS
RMI-R3-9
CHAIN & CLIP
RMI-R3-10
HYDRAULIC
HANDLE
RMI-R3-11
LIFTING ARM SLEEVE
CAUTIONS & WARNING NOTES:
has been designed to handle loads
The RMI-R3 wheel dolly
DO NOT OVERLOAD.
to 1500 pounds.
fluid
When filling hydraulic unit use only hydraulic jack
DO NOT USE HYDRAULIC BRAKE FLUID.
covered by MIL-F-17111.
3
