TM 5-2420-230-10
To avoid possible damage to the starter motor, do not press START button for more than 15 seconds
at a time. If the engine fails to start after three attempts, allow 2 min. for the starter motor to cool
before trying to start engine again. Failure to comply may result in damage to equipment.
Use ether start only while cranking engine. Do not use when engine is already running. Failure to
comply may result in damage to equipment.
(9)
Press and hold START button (2) to crank
engine until engine starts.
NOTE
If engine fails to start, perform Step (10).
(10) While pressing and holding START button (2),
activate ether start by pushing and releasing
button (6) (injecting fluid).
(11) If vehicle will not start after three attempts,
Ensure electrical outlet is unplugged when engine is running. Failure to do so may result in damage to
equipment.
(12) After engine is running, unplug electrical
outlet (7).
5-2.2
Change 1
