TM 9-2320-211-10-1
I
FRAME 5
After dump body (1) is down, move dump body control lever (2) to NEUTRAL
1.
position shown on data plate (3) .
2.
Push safety lock (4) to left side to lock dump body control lever (2) .
3.
Push tailgate control rod hand lever (5) up and toward rear of truck to
close lower tailgate latches (6) , locking tailgate (7) closed.
4.
Step down on clutch pedal (8) all the way.
5.
If TRANSFER CASE lever (9) is in LOW position, move it to HIGH.
6.
Let clutch pedal (8) up.
TA
053946
4-149
