TM 9-2320-211-10-1
FRAME 2
NOTE
Air supply in disabled truck can be charged from towing
truck. This can be done through trailer emergency air
couplings or by using tire inflation hose.
1.
To build up disabled truck air pressure through the emergency
air couplings:
Soldier B
(a) Turn dummy couplings (1) left and take them from emergency
air couplings (2) on disabled truck (left front) and towing
truck (right rear).
(b) Place coupling halves (3) of intravehicular air hose to
emergency couplings (2) of both trucks and turn right to
lock.
Soldier A
(c) Check that engine is running on towing truck.
Soldier B
(d) Turn emergency air valve handles (4) on both trucks 1/4-
turn left to open.
(e) Let air pressure in disabled truck build up to 100 psi shown
Soldier A
on pressure gage (5).
Soldier B
(f) Turn emergency air valve handles (4) on both trucks 1/4-
turn to right to close valves.
(g) Turn coupling halves (3) of intravehicular air hose left and
take them off.
(h) Put dummy couplings (1) on emergency air coupling halves
(2) and turn them right to lock.
GO TO FRAME 3
4-244
