TM 9-2320-211-10-1
FRAME 3
Pull battery boxes (1) of both trucks out far enough for battery posts to be
1.
reached.
CAUTION
Be sure to join positive post of disabled truck battery to
positive post of slave truck battery, and negative post
of disabled truck battery to negative post of slave truck.
This will stop damage to truck battery alternator and
other equipment.
Clamp one end of positve (red) jumper cable (2) to positive battery post of
2.
disabled truck. Clamp other end (3) to positive battery post of slave truck.
Clamp one end of negative (black) jumper cable (4) to negative battery post
3.
of disabled truck. Clamp other end (5) of jumper cable to negative battery
post of slave truck.
GO TO FRAME 4
4-241
