TM 9-2320-269-10
FRONT TIRE - CONTINUED
ACTION
LOCATION
ITEM
REMARKS
REMOVAL - CONTINUED
2 Right front
Lug nuts (2)
Using wrench, loosen.
tire (1)
Do not take off at this time.
3 Right front
Hydraulic jack
a. Position hydraulic jack under
axle (3)
axle (3).
b. Insert handle into hydraulic jack and raise right
front tire (1) until it is 3 to 4 inches (8 to 10 cm)
off the ground.
TA 222700
3-40
