TM 9-2330-246-14
4-108. SMALL AIR INTAKE REPLACEMENT (M373A2C).
This Task Covers:
a. Removal
c.
Installation
b. Cleaning and Inspection
initia/ Setup:
Tools/Test Equipment:
Materials/Parts:
Z Adhesive (Item 2, Appendix E)
Z General mechanic's tool kit
Adhesive (Item 3, Appendix E)
Drill bit set
ZDry cleaning solvent (Item 13, Appendix E)
Electric drill
Two locknuts
Rivet gun
Z Four gaskets
Fifty-seven rivets
REMOVAL
a.
Remove nine rivets (4) securing hinge (3) to semitrailer. Discard rivets.
1.
2.
Open cover (8) and remove 35 rivets (13) securing frame (1) to semitrailer. Remove frame. Discard rivets.
Remove locknut (11) and screw (12) securing each stay (1 O) to frame (1 ). Remove cover (8) and hinge (3) from
3.
frame. Discard locknuts.
4.
Remove nine rivets (5) securing hinge (3) to cover (8), Remove hinge. Discard rivets,
TA700339
4-260
