TM 9-2330-247-14&P
B-5.
EXPLANATION OF COLUMNS IN REMARKS, SECTION IV.
Column 1, Reference Code. The code recorded in Column 6, Section II.
a.
b.
Column 2, Remarks. This column lists information pertinent to the maintenance function being performed as indicated in
the MAC, Section II.
Section II. MAINTENANCE ALLOCATION CHART
(1)
(2)
(3)
(4)
(5)
(6)
GROUP
COMPONENT/
MAINTENANCE
FIELD
SUSTAINMENT
TOOLS AND
REMARKS
NUMBER
ASSEMBLY
FUNCTION
EQUIPMENT
UNIT
DS
GS
DEPOT
C
O
F
H
D
ELECTRICAL
06
SYSTEM
Inspect
0.1
0609
Lights
Replace
0.2
1
Repair
0.5
1
Hull or Chassis Wiring
Inspect
0.1
0613
Harness
Replace
1.5
1
Repair
1.0
1, 2
Intervehicular Cable
Inspect
0.1
Replace
0.5
1
Repair
1.0
1, 2
11
REAR AXLE
Replace
3.0
1, 2
1100
Rear Axle Assembly
Repair
3.0
1, 2
12
BRAKES
1201
Handbrakes
Cable Assembly,
Replace
1.0
1
Handbrake
Handbrake Lever
Adjust
0.2
Replace
1.0
1
Adjust
0.5
1, 2
1202
Service Brakes
Brakeshoe Assembly
Inspect
0.5
1, 2
Replace
1.0
1, 2
Hydraulic Brake
1204
System
Master Cylinder
Replace
0.2
1, 2
Wheel Cylinder
Replace
1.0
1, 2
Lines and Fittings,
Replace
0.2
1
Hydraulic
Change 1
