TM9-2330-372-14&P
5-9. TRUNNION TUBE (Fig. 19).
5-9.1. XM1034 only.
a. Removal.
(1) Remove bogie assembly (para. 5-6).
(2) Block trunnion bar (23).
(3) Remove eight nuts (4 and 5) bolts (15) and plate (6) from each spring assembly (7). Lower trunnion bar
(23) and trunnion brackets (12).
(4) Remove two socket head cap screws (11), lock ring collars (10), bushings (14), trunnion brackets (13) and
ring spacers (19).
(5) Replace all damaged parts.
b. Installation.
Reverse procedure and lubricate lube fittings (22) on ends of trunnion bar (23).
5-9.2. XM1048 only.
a. Removal. XM1048 only.
(1) Remove bogie assembly (para. 5-6).
(2) Block trunnion bar (23).
(3) Remove eight nuts and washers (31 and 32), bolt (27), two clip springs (28) and plate (30) from each
spring assembly (7). Lower trunnion bar (23) and trunnion brackets (12).
(4) Remove two socket head cap screws (11), lock ring collars (10), bushings (14), trunnion brackets (13) and
ring spacers (19).
(5) Replace all damaged parts.
b. Installation.
Reverse procedure and lubricate lube fittings (22) on ends of trunnion bar (23).
Change 1 5-7
