SECTION II
TM 9-2330-383-14&P
C01
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO.
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODE (UOC)
QTY
2000 AND BELOW
1
PAOZZ
52304
805714
BRAKE SHOE .........................................................................................
8
2
PAOZZ
52304
39075
PIN, SHOULDER, HEADLESS................................................................
8
3
PAOZZ
52304
39074
ROLLER, BRAKE SHOE ........................................................................
8
4
PFOZZ
9R200
807497
SPIDER, BRAKE: USED ON 808752 AND 808681 (LEFT
REAR/RIGHT FRONT) ...........................................................................
2
PFOZZ
9R200
807496
SPIDER, BRAKE: USED ON 808753 AND 808680 (RIGHT
REAR/LEFT FRONT) .............................................................................
2
5
PAOZZ
9R200
089899
BOOT, DUST AND MOISTURE SEAL: USED ON 808680
AND 808681 ............................................................................................
4
6
PAOZZ
52304
1000693
DEFLECTOR, DIRT AND LIQUID ...........................................................
4
7
PFOZZ
9R200
808751
BRACKET, BRAKE CAMSHAFT: LEFT REAR-USED ON 808752 .........
1
PFOZZ
9R200
808750
BEARING UNIT, PLAIN: RIGHT REAR-USED ON 808753 .....................
1
PFOZZ
9R200
807488
BRACKET ASSEMBLY, CAM: LEFT FRONT-USED ON 808680 ...........
1
PFOZZ
9R200
807489
BRACKET ASSEMBLY, CAM: RIGHT FRONT-USED ON 808681 .........
1
8
PAOZZ
52304
90414
WASHER, LOCK.....................................................................................
16
9
PAOZZ
96906
MS90725-302
SCREW, CAP, HEXAGON HEAD ...........................................................
16
10
PAOZZ
52304
43943
WASHER, FLAT: THICKNESS .0598......................................................
4
11
PAOZZ
76301
4M36-11008
WASHER, FLAT: THICKNESS .063........................................................
4
12
PAOZZ
52304
23570
WASHER, FLAT: THICKNESS .031........................................................
8
13
PAOZZ
79136
5304-125
RING, RETAINING ..................................................................................
4
14
PAOZZ
78502
427-10401
BRACKET, VEHICULAR COMPONENTS...............................................
4
15
PAOZZ
7P109
1001353
PARTS KIT, BRAKE MOUNTING BRACKET: USED ON REAR
BRAKES ONLY.......................................................................................
2
16
PAOZZ
52304
804023
SCREW, MACHINE.................................................................................
20
17
PAOZZ
96906
MS51968-20
NUT, PLAIN, HEXAGON .........................................................................
32
18
PAOZZ
96906
MS35335-39
WASHER, LOCK.....................................................................................
32
19
PAOZZ
81142
1000406
SPRING, HELICAL, EXTENSION ...........................................................
4
20
PAOZZ
80204
B1821BH063F175N
SCREW, CAP, HEXAGON HEAD ...........................................................
32
21
PFOZZ
9R200
807615
CAMSHAFT, ACTUATING, BRAKE SHOE: LEFT REAR-
USED ON 808752....................................................................................
1
PFOZZ
9R200
807614
CAMSHAFT, ACTUATING, BRAKE SHOE: RIGHT REAR-
USED ON 808753....................................................................................
1
PFOZZ
9R200
070308
CAMSHAFT, ACTUATING, BRAKE SHOE: LEFT FRONT-
USED ON 808680....................................................................................
1
PFOZZ
9R200
070309
CAMSHAFT, ACTUATING, BRAKE SHOE: RIGHT FRONT-
USED ON 808681....................................................................................
1
22
PAOZZ
9R200
070326
SPRING, HELICAL, EXTENSION ...........................................................
8
23
PAOZZ
9R200
1001811
MARKER, IDENTIFICATION ...................................................................
4
END OF FIGURE
