TM 9-2350-222-10-2
PREPARE FOR FIRING (ADJUST SIGHTS) - Continued
To Sight Gunner's M32CE1 Periscope Passive Body If Vehicle
Power Is Not Available:
NOTE
Two types of instrument lights (M30 and M50)
are stowed on vehicle. If M30 is not stowed at
gunner's station, it is stowed in commander's
cupola. See page 2-360.4 for location of M30 in
commander's cupola.
1.
Remove cable (A) from M30 instrument light (B).
2.
Connect cable (A) to connector (C).
3.
Push light shutter lever (D) left to open shutter.
4.
Turn switch (E) all way clockwise (ON).
TA252781
Change 1 2-368.3
