TM 9-2350-277-10
TOWING TRAILER WITH CARRIER -- Continued
0079 00
10.
Stow pintle extender. Unlock linchpin and remove t-handle pin and allow extender bracket to swing down 90 degrees.
Reinstall t-handle pin and lock with linchpin to secure bracket in down position.
PINTLE
HOOK
LATCH
TOW
BAR
COTTER
TOW
PIN
PINTLE
END OF TASK
Change 3
0079 00-6
