Figure 2-3. Location of Information Plates.

TM 9-4120-399-14

e. Adjust louvers to suit. Since cold air tends to flow downward, it is normally better to

adjust the conditioned air outlet louvers slightly upward. The conditioned air inlet louvers should

be full open.

2-12. SHUTDOWN. Turn the mode selector switch to OFF.

NOTE

DO NOT disconnect or turn off power to the air conditioner during periods

of normal shutdown. If power is disconnected, the heater and thermostat

inside the compressor will not allow the unit to be operated in the COOL

mode until 30 minutes after power has been reconnected. Power should be

disconnected only if unit is to be serviced, during emergency conditions, or

during periods of extended shutdown.

2-13. PREPARATION FOR MOVEMENT. When the unit is to be moved, the services of unit

maintenance shall be employed for the necessary preparations. See Chapter 4, Section VII.

2-14. INFORMATION PLATES. Refer to Figures 2-3 and 2-4 for the locations and text of the

identification and information plates on the air conditioner.

Figure 2-3. Location of Information Plates.
