TM 9-4120-401-14
ELECTRICAL WIRING REPAIR - GENERAL. - continued
4-24.
(3) Splicing Wires.
To repair broken or cut wires that are otherwise sound, the mating ends can be stripped and spliced.
Solder and apply insulation as described above.
(4) Crimping Terminals.
To install a terminal on the end of a wire, strip 1/4 - 1/2 inch (0.6 -1.3 cm) of insulation fromm the end of the
wire, apply a one-inch (2.5 cm) piece of heat-shrink tubing (if the terminals are of the uninsulated type).
Insert wire-end into the shank of the terminal. Crimp the shank and install heat-shrink tubing, if
necessary.
NOTE
Preferred repair methods consist of replacing wires, terminals, connectors, etc.,
rather than splicing wires, bending ends to form terminals, and other make-shift
procedures, although the latter may be appropriate for emergency field repairs.
(5) Determine the proper size and length of wire, or the terminal, or connector to be used for replacement
AWG
Length
Termination
Termination
Wire
To
Terminal Type
Size
IN.
From
Terminal Type
CM
K2-A2
23.5
MS25036-112
12
P11-A
59.7
K2-B2
12
24.2
MS25036-112
P11-B
61.3
K2-C2
12
24.8
P11-C
MS25036-112
62.9
16
P11-D
MS25036-108
S6-2
34.0
86.4
TB1-1
P11-F
16
MS25036-108
33.5
85.1
TB1-2
P11-G
16
MS25036-108
34.2
86.9
15.0
P11-F
16
13229E4273
J7-2
38.1
S7-1
16
MS25036-108
J7-1
35.0
88.9
LEAD, ELECTRICAL
E1
MS25036-153
16
TB2-5
10.0
25.4
13216E6191-2
MS25036-108
16
K2-A2
29.0
73.7
CR4-1
13216E6191-2
K2-B2
MS25036-108
29.0
CR4-4
16
73.7
13216E6191-2
MS25036-108
16
75.0
S2-2
S6-1
190.5
MS25036-108
MS25036-108
S7-2
16
60.0
S3-2
152.4
MS25036-108
TB1-1
16
MS25036-108
21.5
K1-A1
54.6
MS25036-108
TB1-2
K1-B1
16
MS25036-108
21.5
54.6
MS25036-108
K1-C1
TB1-3
16
MS25036-108
21.5
54.6
T1-3
16
CR1-1
14.4
36.6
T1 -4
CR1-3
16
14.4
36.6
MS25036-108
T1 -1
TB1 -2
16
16.5
41.9
T1 -2
TB1-1
MS25036-108
16
17.5
44.5
K1-X1
MS25036-153
CR1-2(+)
16
15.5
39.4
K2-X1
MS25036-153
CR1-2(+)
16
32.0
81.3
13216E6191-2
CR4-2
L1-1
13216E6191-2
16
12.0
30.5
13216E6191-2
CR4-3
L1-2
13216E6191-2
16
12.0
30.5
