TM 9-4120-403-14
Removal
(1) Remove screw and clamp from remote sensing bulb.
(2) Remove grommet from bulkhead.
CAUTION
Take care that sensing bulb capillary line is not kinked and that bulb and capillary are not cut or damaged
when removing.
(3) Carefully slip remote sensing bulb down through bulkhead.
(4) Remove four screws that secure control panel to junction box and remove control panel.
Installation
(1) Secure control panel to junction box with four screws.
CAUTION
Take care that sensing bulb capillary line is not kinked and that bulb and capillary are not cut or damaged
during installation
(2) Carefully feed sensing bulb and capillary up and into conditioned air intake compartment.
(3) Secure remote sensing bulb with clamp and screw.
(4) Install grommet in bulkhead.
(5) Secure capillary tube and grommet in panel with sealant.
(6) Coil excess capillary tubing in recess behind control panel.
Follow-on procedures:
(1) Install junction box. (See para 4-32.)
(2) Install air filter. (See para 4-23.)
4-56
