TM
9-2320-366-10-2
2-45.
M998
SERIES
TOWING
CONNECTION/DISCONNECTION
a. Front
Connection.
(1)
Remove
two
top
bumper
lift
tools
(1),
chains
(2),
emergency
tow
lights
(3),
and
tow
lights
cable
(4)
from
tool
box.
(2)
Prepare
underlift
assembly
for
operation
(para
2-44a).
NOTE
Perform
step
3 if
assistant
is
not
available
to
aid
in
towing
connection.
(3)
Connect
WRECKER
REMOTE
CONTROL
(para
2-44b).
Change
1
2-493
