TM 9-2330-231-14&P
HYDRAULIC BRAKE LINES AND FITTINGS - CONTINUED
ACTION
LOCATION
ITEM
REMARKS
CYLINDER-TO-CYLINDER BRAKE TUBE INSTALLATION
19.
Backing plate (1)
Fitting (2)
Place in position.
20.
Fitting (2)
Bolt (3)
Using 7/16-inch socket, install.
21.
Bolt (4), new
Using 3/4-inch wrench, assemble and
washers (5 and 6),
install.
and connector (7)
22.
Backing plate (1)
Two bolts (8), two new
Using 3/4-inch wrench, assemble and
washers (9 and 10),
install.
and two connectors (11)
23.
Fitting (2) to
Brake lines
Place in position.
connectors(n)
(12 and 13)
24.
Brake lines
Two nuts (14)
Using 7/16-inch wrench, install.
(12 and 13)
Repeat steps 19 thru 24 for opposite wheel.
CHASSIS BRAKE TUBE INSTALLATION
Brake line will be in two pieces until union is installed.
25.
Left frame
Brake line (16)
Place both halves in position.
rail (15)
26.
Union (17)
Two nuts (18)
Using two 7/16-inch wrenches, install.
27.
Brake line (16)
Three screws (19),
Using cross-tip screwdriver, assemble
three washers (20),
and install.
and three clamps (21)
28.
Master
Fitting (23) and
Using 5/8-inch wrench, install.
cylinder (22)
new gasket (24)
29.
Nut (25)
Using 5/8- and 7/16-inch wrenches, install
into fitting (23).
4-64
