TM 9-2330-231-14&P
QUICK DISCONNECT AIR COUPLING (GLADHAND - FRONT)
This task covers:
a. Removal (page 4-101)
b. Installation (page 4-102)
INITIAL SETUP
Tools
Wrench, open-end, 15/16-inch
Wrench, open-end, 1 1/16-inch
Wrench, open-end, 1 1/8-inch
ACTION
LOCATION
ITEM
REMARKS
REMOVAL
NOTE
Do steps 1 and 4 when removing an unserviceable gladhand. Do steps 2 and 3
when
removing gladhands from an unserviceable hose.
1.
Service or emer-
Gladhand (2)
Remove using 15/16- and 1 1/8-inch
gency airhose (1)
wrenches.
2.
Gladhand (2) and
Using 15/16- and 1 1/16-inch
body (3)
wrenches, remove from hose (1).
4-101
