TM 9-2330-235-14&P
4-17. REAR AXLE ASSEMBLY REPLACEMENT (M390C) (Con't).
2. Loosen two nuts (5) at each turnbuckle (6).
Remove tumbuckles from push-pull control
assemblies (7) and rods (4).
3. Raise retractable support assembly (para 2-8).
4. Remove eight nuts (8) and two U-bolts (10)
securing each end of axle (11) to springs (9).
4-28
