TM 9-2330-297-14&P
BOGIE ASSEMBLY
This task covers:
a. Removal (page 4-46)
b. Installation (page 4-48)
INITIAL SETUP
Tools
Materials/Parts
Chain sling
Chock blocks (four each)
Jack stands (four each)
Wrench, open-end, 9/161nch
ACTION
LOCATION
ITEM
REMARKS
REMOVAL
1.
Chassis rear
Rear bumper (1)
Store rear bumper (1).
See page 3-15.
2.
Bogie (2)
a. Place chocks (3) in front and back of
wheels.
b. Using jack stands (4), support bogie
assembly (2).
Place one jack stand in front and one
in back.
3.
Bogie (2)
Airhoses (5)
Uncouple airhoses (5) from semitrailer
chassis fittings.
4.
Pull handle
Using 9/16-inch wrench, unscrew enough
lock (6)
to release pull handle (7).
5.
Pull handle (7)
Disengage pull handle (7), move downward
and engage in lower slot to disengage bogie
lockpins.
b. Slide bogie (2) off chassis (8).
6.
Semitrailer
Chain sling (9)
Attach sling (9) to chassis (8).
Sling (9) Is to lift chassis (8) In a
chassis (8)
level and balanced condition.
4-46
